Zinc Plating Additives
Created with Pixso. Durable Uniform Alkaline Zinc Nickel Alloy Coating Process

Durable Uniform Alkaline Zinc Nickel Alloy Coating Process

Brand Name: AOBANG
MOQ: 25-30kg
Delivery Time: 5-8 work day
Payment Terms: T/T
Detail Information
Place of Origin:
China
Features:
Durable, Uniform Coating
Product Type:
Alkaline Zn-Ni Alloy Process
Zinc Concentration:
8.0 G/L
Sodium Hydroxide:
120.0 G/L
Operating Temperature:
10-45 ℃
Cathode Current Density:
0.5-6 A/dm²
Packaging Details:
25kg/drum
Highlight:

Durable Zinc Nickel Alloy Coating Process

,

Alkaline Zinc Nickel Alloy Coating Process

Product Description
R • G-2007 alkaline galvanizing
Product Introduction
  1. It is an alkaline zinc deposition process suitable for cyanide free hanging plating or rolling plating.
  2. Good electroplating results can be achieved in high concentrations of zinc and caustic soda.
  3. Under working current density, the coating has excellent dispersion, which can save zinc metal.
  4. The galvanized layer is easy to passivate.
Process Parameters
Parameter Value
Zinc concentration 8.0 g/L
Caustic soda 120.0 g/L
R • G-2007 Cylinder Opening Agent 12.0 ml/L
R • G-2007 regulator 2.0 ml/L
R • G-2007 Purifier 2.0 ml/L
R • G-2007 Brightener 2.0 ml/L
Temperature 10-45 ℃
Dk 0.5-6A/dm2
Advantage
  • High concentration
  • Good dispersion performance of the coating
  • Excellent positioning performance
  • Good ductility
  • Can work at high current density
  • Low operating costs
Equipment
  • Plating tank: Steel layer with PP or PVC.
  • Filtering: Filter with a 10um filter cartridge.
  • Anode: Zero zinc anode or low-carbon steel plate.
  • Filtration: Continuous (1-2 volume solutions per hour) is required.
  • Cooling: It is necessary as high temperatures (above 40 ° C) consume a significant amount of R · G-2007 brightener.
  • Stirring: Requires cathode movement.
